| Material Number | 1878096 |
| ISO Catalog ID | A2TZN3225J32 |
| ANSI Catalog ID | A2TZN3225J32 |
| [HW] Shank Height | 32 mm |
| [HW] Shank Height | 1.259 in |
| [H] Shank Height | 32 mm |
| [H] Shank Height | 1.259 in |
| [B] Shank Width | 25 mm |
| [B] Shank Width | .9843 in |
| [F] F Dimension | 36.5 mm |
| [F] F Dimension | 1.437 in |
| [H2] Overall Height | 49.5 mm |
| [H2] Overall Height | 1.95 in |
| [B2] Overall Width | 42 mm |
| [B2] Overall Width | 1.653 in |
| [H3] Head Bottom Offset | 3 mm |
| [H3] Head Bottom Offset | .1181 in |
| [L] Overall Length | 110 mm |
| [L] Overall Length | 4.33 in |
| Clamp Screw ID Drive Size | 5 mm |
