| Material Number | 5512462 |
| ISO Catalog ID | CNMG160612RN |
| ANSI Catalog ID | CNMG543RN |
| Grade | KCPK05 |
| [D] Insert IC Size | 15.875 mm |
| [D] Insert IC Size | 0.625 in |
| [L10] Insert Cutting Edge Length | 16.12 mm |
| [L10] Insert Cutting Edge Length | 0.6346 in |
| [S] Insert Thickness | 6.35 mm |
| [S] Insert Thickness | 0.25 in |
| [Rε] Corner Radius | 1.2 mm |
| [Rε] Corner Radius | 0.047 in |
| [D1] Insert Hole Size | 6.35 mm |
| [D1] Insert Hole Size | 0.25 in |
Grades
KCPK05
Composition: A deformation-resistant, cobalt-enriched substrate combined with thick MTCVD TiCN-Al2O3 coating.
Application: For high productivity turning of steels and PH stainless steels in continuous to lightly interrupted cuts. This grade provides excellent combination of toughness and high speed wear resistance allowing the fastest steel part production. Its unique combination of substrate and coating also make it an ideal roughing grade for cast iron where chipping resistance is required.
Create Solution to calculate Feeds and Speeds
After creating a solution just choose the Feeds & Speeds icon and our system will provide recommendations. You can customize the information by adding your machine and specifications or make adjustments using the sliders.
