HF TreatmentDownloaded file will be available after import in the {{cadTool}} tool library.
| Número de material | 2974455 |
| Referencia ISO | U200TB HF BLOCK |
| Referencia ANSI | U200TB HF BLOCK |
| Superficie de asiento de diámetro [DSS] | 71.9 mm |
| Superficie de asiento de diámetro [DSS] | 2.83 in |
| Adaptador/Mango/Diámetro de mandrinado [D1] | 53.1 mm |
| Adaptador/Mango/Diámetro de mandrinado [D1] | 2.09 in |
| Segundo adaptador/mango/diámetro de orificio [D1S] | 40.6 mm |
| Segundo adaptador/mango/diámetro de orificio [D1S] | 1.6 in |
| Altura total [H2] | 88.4 mm |
| Altura total [H2] | 3.48 in |
| Longitud total [OAL] | 120.65 mm |
| Longitud total [OAL] | 4.75 in |
