| Material Nummer | 1011397 |
| ISO Katalog Nummer | D16JS0485143 |
| ANSI Katalog Nummer | D16JS0485143 |
| EW_HLD_CORE_BODY_DIA_M | 15.875 mm |
| EW_HLD_CORE_BODY_DIA_I | .625 in |
| EW_HLD_BODY_DIA_WKPS_M | 25.4 mm |
| EW_HLD_BODY_DIA_WKPS_I | 1 in |
| [L1] Messlänge | 1219.2 mm |
| [L1] Messlänge | 48 in |
| [LRO] Aufnahmelänge Offset | 7.92 mm |
| [LRO] Aufnahmelänge Offset | .312 in |
| [DVSM] Mitnehmergröße Maschinenseite | 5/8 Hex Female |
