| Número de material | 3791292 |
| ID do catálogo ISO | A4G0405M04U04GUP |
| ID do catálogo ANSI | A4G0405M04U04GUP |
| Grade | KCP10 |
| Insert Size | 4 |
| [W] Cutting Width | 4.12 mm |
| [W] Cutting Width | 0.162 in |
| [RR] Corner Radius | 0.4 mm |
| [RR] Corner Radius | 0.016 in |
| [LI] Insert Length | 20.15 mm |
| [LI] Insert Length | 0.793 in |
| [T] Cuttg Depth | 3.4 mm |
| [T] Cutting Depth | 0.134 in |
Classes
KCP10
Composition: A specially engineered cobalt-enriched carbide grade with thick MTCVD-TiCN-Al2O3 coating for maximum wear resistance.
Application: An excellent finishing to medium machining grade for a variety of workpiece materials, including most steels, ferritic, martensitic, and PH stainless steels, and cast irons. The cobalt-enriched substrate offers a balanced combination of deformation resistance and edge toughness, while the thick coating layers offer outstanding abrasion resistance and crater wear resistance for high-speed machining. Smooth coating provides resistance to edge build-up and microchipping and produces excellent surface finishes.
Criar solução para calcular avanços e velocidade
Após criar uma solução basta escolher o ícone Avanços & Velocidades e o nosso sistema irá fornecer recomendações. Pode personalizar as informações adicionando a sua máquina e especificações ou fazer ajustes utilizando os controlos deslizantes.
